E-Bike: Tenways CGO600 Plus 360 Wh E-Bike Diamant 28 Zoll pebble grey ... minimalistisches Design trifft auf moderne Technik für deinen urbanen Alltag. Ob auf dem Weg zur Arbeit oder durch die City: Dieses leichte E-Bike bringt dich komfortabel und stilvoll ans Ziel.
Mit dem leistungsstarken Tenways C9 Hinterradmotor erlebst du eine sanfte Beschleunigung, während der intelligente Drehmomentsensor die Unterstützung exakt an deine Tretkraft anpasst. Du genießt ein besonders natürliches und harmonisches Fahrgefühl bei jeder Fahrt.
Specs auf einen Blick
- Motor: Tenways C9 Nabenmotor (Leistung: 250 W, max. Drehmoment: 45 Nm)
- Akku: Lithium-ion Battery 36V, 10AH, LG-21700 cell 5000MAH*20, 360 Wh
- Display: Star Union, SW102/T Kompaktes OLED-Display
- Schaltung: Shimano Claris 8-fach (Schaltwerk: Shimano RD-R2000, GS, 8-SPEED)
- Schalthebel: Shimano Claris SL-R2000
- Bremsen: Tektro HD-M275 Scheibenbremse (vorne und hinten)
- Bremsscheiben: Tektro TR160-52
- Rahmen: 6061 Aerospace Aluminium-Rahmen, Diamantform, grau
- Gabel: TENWAYS CGO600PLUS Aluminum Starrgabel
- Reifen: CST C-1880, 28*1.75*2.00, EPS stab-proof, anti-abration, reflective stripe
- Laufradgröße: 28 Zoll
- Felgen: LYE-026B, aluminum, double-deck, matt black, 700C*1.5
- Speichen: Edelstahl 304H (vorne: 13G 260mm & 14G 290mm; hinten: 14G 286mm & 13G 261mm)
- Nabe Vorderrad: RX-25, two bearing disc brake type, aluminum, black, QR24
- Kurbelgarnitur: NWA48A-S1-3, 48T (CNC)
- Antrieb: Kette, 1 Kettenblatt
- Tretlager: Vollständig verdecktes Tretlager
- Lenker: MHB-6045BT, aluminum, matt black, straight, 620 mm breit
- Vorbau: CAS-JD6601N-8/0, aluminum, SABK matt black, integriert, verstellbar -20 bis +90 Grad
- Sattel: Aifeit, black leather, 271*148 mm
- Sattelstütze: RSP-AD001, aluminum, matt black, 30.4*350 mm, ungefedert
- Griffe: HL-G318, rubber, black, 130 mm
- Pedale: FP-877ZP, engineering plastic composite, black
- Beleuchtung: DHY05 LED Frontlicht (6V) und Mudguard rear light (6-48V) mit Reflektor
- Schutzbleche: NB70K-600PLUS-002, aluminum, matt black, 58mm Breite
- Ständer: YX-KS11D, aluminum, matt black, verstellbar 285-355 mm
- Controller: Vektor-Sinuswellen-Controller
- Sensor: Drehmomentsensor
- Ladegerät: MDA254, 36V/42V, 3A
- Max. Systemgewicht: 120 kg
- Steuersatz: KL-B570HT, hidden toothless bearing
Fuer wen geeignet
Dieses E-Bike ist die ideale Wahl für Pendler und Stadtbewohner, die ein wartungsarmes und ästhetisches Fortbewegungsmittel suchen.
Merkmale
| Bremshebel vorne: | Tektro, HD-M275, with 750mm oil tube |
| Bremshebel hinten: | Tektro, HD-M275, with 1550mm oil tube |
| Akku: | Lithium-ion Battery 36V, 10AH, LG-21700 cell 5000MAH*20, limit 15A, BMS/CANBUS, (carton size:510*110*150mm) |
| Bremse: | Tektro, HD-M275 |
| Display: | Star Union, SW102/T Kompaktes OLED-Display |
| Gabel: | TENWAYS CGO600PLUS Fork, Aluminum |
| Griffe: | HL-G318, rubber, black, 130 mm, single pass, w/ aluminum anode black locking ring |
| Kurbelgarnitur: | NWA48A-S1-3,3/32*48T, FD05-48T (CNC) |
| Lenker: | MHB-6045BT, aluminum, matt black, straight handlebar, W:620 mm*1.8T, ø31.8 mm, 6°, grip width?185 mm, w/o LOGO, ISO-M standard |
| Motor: | TENWAYS C9 Nabenmotor (Leistung: 250 W, max. Drehmoment: 45 Nm) |
| Pedale: | FP-877ZP, engineering plastic composite material, black, 9/16", w/ bead, BS/CPSC/DIN standard reflector, ISO-M, stick 'L' & 'R' label as dwg: PD21-0001 |
| Rahmen: | 6061 Aerospace Aluminium-Rahmen |
| Reifen: | CST, C-1880, rubber, black, EPS stab-proof, anti-abration, reflective stripe28*1.75*2.00, CST tire, 60TPI |
| Rücklicht: | Mudguard rear light, 6~48V, black plastic shell, red light cover, w/ reflector, cable w/ end 1270 mm(G2.6 male end, blue for positive and black for negative), w/ black screw |
| Sattel: | Aifeit, 62450-04#S04, black leather, w/o pattern, black protective cover, BED bridge+scale, w/o LOGO, 271*148 mm |
| Sattelstütze: | RSP-AD001, aluminum, matt black, ø30.4*350 mm, laser carving safety line and scale, w/ black clip, black screws, w/o LOGO, ISO-M standard |
| Schalthebel: | Shimano Claris SL-R2000, 8-fach |
| Schaltwerk: | Shimano RD-R2000,CLARIS,GS,8-SPEED,DIRECT,ATTACHMENT,BULK |
| Scheinwerfer: | DHY05, front light, LED, 6V, w/ 2 core cable w/ end 125 mm(Bafang M2.6 female end), CE/ROHS, w/ 2PCS black countersunk cross screw M3*10, black rubber plug 2PCS |
| Schutzbleche: | NB70K-600PLUS-002, front / rear mudguard D58, aluminum, matt black, width 58MM, height 19mm, black stainless steel stay, w/ adjuster and black screws accessories(mudguard stay black outer clip/ original color inner clip), front fixed hanger, no rear hanger, print LOGO as dwg MD21-0003 |
| Speichen: | Front: stainless steel 304H, 13G, 260 mm, black& stainless steel 304H, 14G, 290 mm. Rear: stainless steel 304H, 14G, 286 mm, black& stainless steel 304H, 13G, 261 mm, black |
| Ständer: | YX-KS11D, aluminum, matt black, 285-355 mm adjustable, lock hole distance 40 mm, w/ 2PCS black screws M6*20 mm(w/ teflon paste, w/ outer diameter ?10 spacer), plastic black kickstand |
| Steuersatz: | KL-B570HT, hidden toothless bearing head set, for head tube inside cable, cable hole 7.8*15 mm, material:A6061, black, ø28.6*ø51.8*ø51.8*ø39.8, H:11.5 mm, w/ star/black cylinder hex screw M6*40 mm, w/o aluminum cover |
| Tretlager: | Vollständig verdecktes Tretlager |
| Vorbau: | CAS-JD6601N-8/0, aluminum, SABK matt black, intergrated, E:110 mm, ?31.8 mm for hadndlebar, ?28.6*35 mm for fork, angle adjustable:-20° to +90°, w/o LOGO, original angle 110°, all accessories are black |
| Vorderrad Nabe: | RX-25, two bearing disc brake type, aluminum, anode black, M9*14G*36H*100*108, shaft core 45#, w/ QR24 aluminum black quick release, inner width L:112 mm, w/o LOGO |
| Sensor: | Drehmomentsensor |
| Bremsscheibe hinten: | Tektro, TR160-52 |
| Bremsscheibe vorne: | Tektro, TR160-52 |
| Max. Systemgewicht: | 120 kg |
| Felge vorne: | LYE-026B, aluminum, double-deck, matt black, 700C*1.5*14G*36H, height 18, inner width 20, outer width 27, A/V valve (w/o logo) |
| Felge hinten: | LYE-026B, aluminum, double-deck, matt black, 700C*1.5*13G*36H, height 18, inner width 20, outer width 27 |
| Ladegerät: | MDA254, for lithium battery, 36V/42V, 3A input voltage 100-240V, 50/60Hz, DC2.1 charger plug, AC plug EU standard/C type, CE standard, packing size:218*138*55MM |
| Controller: | Vektor-Sinuswellen-Controller |
