Merkmale
| Bremshebel vorne: | Tektro, HD-T275, with 900 mm oil tube |
| Bremshebel hinten: | Tektro, HD-T275, with 1650 mm oil tube |
| Kettenblatt/Riemenscheibe: | Gates, CDX, CT11605AA, 60T, BCD:130 mm, fit for 5-arm, aluminum alloy(black) |
| Akku: | Lithium-ion Battery,36V,13.2AH,EVE-18650 cell 3300MAH,40pcs cells, limit 15A,CANBUS,YS7781 100%,Sky Blue |
| Antrieb: | Single-Speed-Antrieb/Gates Carbon Riemenantrieb |
| Bremse: | Tektro, HD-M275 |
| Display: | Integriertes Smart-LCD-Display |
| Gabel: | SR suntour Fork 700C C-GO 800S alloy,SF24-NEX-E25-DS-700C-63,black |
| Gepäckträger: | Rear carrier, aluminum, matt black |
| Griffe: | G220, black PU, 130 mm, bi-pass, w/ black HL-05 plug (ø19.9), w/ aluminum anode black locking ring |
| Kurbelgarnitur: | Prowheel, EB08 (SOLID), 170 mm, matt black LH/RH, for 9/16" |
| Sensor: | Drehmomentsensor |
| Lenker: | CHB-A6353 and add 2 cable threading holes as CBH-C-G800-002C, aluminum, matt black, riser handlebar, W:635 mm*2.2T, fit with stem ?31.8 mm, H:41 mm, 37°, grip distance?185 mm, w/o LOGO |
| Motor: | Mivice M070 250W 40Nm Hub Motor |
| Pedale: | FP-877ZP, engineering plastic composite material, black, 9/16", w/ bead, BS/CPSC/DIN standard reflector, ISO-M, stick 'L' & 'R' label |
| Rahmen: | 6061 Aluminiumrahmen |
| Reifen: | CST, C1635, rubber, 60TPI, black, 28"*2.0"(700*48C), 3 mm orange stab-proof, w/ reflective stripe |
| Rücklicht: | Sate-Lite,M4(all red,w/ brake sensor),mudgurad rear light,6~48V,black plastic shell,red light cover |
| Sattel: | SELLE ROYAL, black 8014#/vacuum foaming/ bridge BED print 065# scale mark, no clip/no edge |
| Sattelstütze: | RSP-AD001, aluminum, matt black, ø30.4*350mm, laser carving safety line and scale, w/ black clip, black screws, ISO-M standard |
| Scheinwerfer: | DH002, 36V, LED, Black, with 50 mm waterproof cable |
| Schutzbleche: | NB28-CGO800-003D, D58, aluminum, 2.0T matt black, wide 58mm, height 19mm, w/ black stainless steel stays (L=255mm), w/ black adjuster and screw accessory, w/ CP-001 connecting clip, front fixed hanger, rear fixed hole, cable hole on left of rear mudguard |
| Speichen: | Stainless steel 304H,14G,290mm,black,w/ 16mm& stainless steel 304H,14G,286mm,black,w/ 16mm& stainless steel 304H,13G,267mm,black,w/ 16mm |
| Ständer: | YX-KS11C, aluminum, matt black, 285-355MM adjustable, lock hole distance 40MM, w/ 2PCS black screws M6*20MM(w/ teflon paste, w/ outer diameter ?10 spacer), plastic black kickstand |
| Steuersatz: | FP-H869T, hidden toothless head set, aluminum, matt black, ?28.6*?41.8*52*?39.8, H:11.2 mm, w/o locker |
| Bremsscheibe hinten: | Mivice Rotor, 2Cr13, 160 mm, for M070 motor,w/ 6pcs of srcew T25_M5×9 |
| Bremsscheibe vorne: | PRT006-160, cassette disc, high polish Shimano standard, disc outer diameter 160 mm |
| Vorderrad Nabe: | RX-25, 2 bearing disc rotor type, aluminum, anode black, M9*14G*36H*100*108, shaft core 45#, w/ QR24 aluminum black quick release, L:115 mm |
| Max. Systemgewicht: | 120 kg |
| Felge vorne: | LYE-026B, aluminum, double-deck, matt black, 700C*1.5*14G*36H, height 18, inner width 20, outer width 27 |
| Felge hinten: | LYE-026B, aluminum, double-deck, matt black, 700C*1.5*13G*36H, height 18, inner width 20, outer width 27 |
| Ladegerät: | MDA254, for lithium battery, 36V/42V, 3A input voltage 100-240V, 50/60Hz, DC2.1 charger plug, AC plug EU standard/C type, CE standard, packing size:218*138*55 mm |
| Controller: | Mivice C201 Controller |
